The LXV 4.7 is a compact off-road hybrid with plenty of features.
LXV 4.7: Compact, versatile and lightweight pure offroad hybrid
Internal Length: 4612mm
Overall Length: 6310mm
Internal Width: 1910mm
Overall Width: 2090mm
Internal Height: 1930mm
Overall Height: 2905mm standard air bag height
2855mm low air bag height
Tare Weight: 2076kg
ATM: 2850kg
Ball Weight: 180kg
Fresh Water: 125 Litres + 75 Litres
Grey Water: 85 Litres
Black Water: 18 Litres
Diesel Tank: 12 Litres
Roof mounted 730 watt solar array
600AH lithium batteries
REDARC Alpha100 TVMS with dual RedVision touchscreen panels
3000W pure sine wave inverter
Electronic air suspension with multi ride height
Electronic dust suppression system
Electric open/close awning
Wall mounted Starlink connections (does not include panel or subscription)
Face to face dinette - plush microfibre leather lounge with swivel table
Diesel hot water & heater
Roof mounted reverse cycle air conditioner
Combined internal shower, toilet & basin
Slide-out stainless steel swing kitchen and bench with sink and 3 burner gas stove
External slide out 95L refrigerator
Microwave
Queen-sized inner spring mattress under-bed storage
Optional extras available in our brochure
DISCLAIMER: Mountain Trail RV and its authorised dealers, retains the right to change designs, dimensions, weights, fittings, finishes, options and specifications without notice. Fittings and finishes are subject to availability and supplier discretion.
LXV 4.7 Hybrid
Off-Road Caravan
Features.
LXV 4.7 Off-Road Hybrid: Redefining Off-Grid Comfort
Dimensions & Weights.
With a tare weight of 2,076kg and an ATM of 2,850kg, the LXV 4.7 offers exceptional towing versatility. Its lightweight yet robust design means you have the freedom to choose from a wide range of tow vehicles, making every adventure effortlessly achievable.
Compact Smart
Design.
Every inch of the LXV 4.7 is engineered for maximum efficiency, ensuring you get the most out of your hybrid off-road caravan. Modular, rugged, and fully self-contained, it’s built to handle any adventure with ease.
Stainless Steel Slide Out Swing Kitchen
Our uniquely designed stainless steel slide-out swing kitchen lets you prepare gourmet meals no matter where your adventure takes you. With ample bench space, a built-in sink, and a three-burner gas stove, cooking on the road has never been easier.
Best of all, the swing-out slide kitchen comes standard with every brand-new LXV 4.7.
Off-Road Technology.
Equipped with MTRV-designed independent trailing airbag swing arm suspension, 12-inch electric brakes, and a DO35 coupling, the LXV 4.7 is built to handle any adventure. The multi-ride height suspension allows for quick and effortless leveling at the touch of a button, ensuring a smooth and stable setup wherever you venture.
Electrical Components.
Enjoy crystal clear sound with Fusion Entertainment system with both internal and external speakers. 12 volt USB connectivity and 240v sockets throughout all managed by the Redarc Redvision Total Vehicle Management System.
European Composite Wall Panels.
We’ve sourced the best materials in the world to ensure our off-road caravans have the highest insulation properties available. Precision cut in our factory from whole panels utilising CNC (Computer Numerically Controlled) machinery.
MTRV Suspension.
The LXV 4.7 is ready to take to the off-road and the harshest of conditions. The MTRV engineered independent trailing swing arm suspension, 4 shock absorbers and multi ride height self-leveling air bags are built to last.
Dust Suppression.
With positive pressure technology in your LXV 4.7 you have the peace of mind that dust will be deterred from entering your off-road caravan. No more pulling up to find a dust filled caravan.
Luxury & Comfort.
After a long day touring there is nothing better than retreating to the luxury of the LXV 4.7. You will have a restful sleep in the full size queen pillowtop mattress with outside noise cancelled out by the high rated insulation properties of the outer composite shell .
Solar Power.
Enough power to stay off grid and leave the boundaries of traditional caravan parks. 730 watt solar system, 600-Amp lithium batteries and a 3000-watt inverter enable you to use 240 volt appliances with no power drop offs.
Air conditioning is also a standard inclusion on the LXV 4.7.
Front Storage Box.
The LXV 4.7’s front storage box is designed to shield your van from stones and road debris, ensuring lasting protection on every journey. Coated and sealed with durable rubberised paint, it features a vented compartment with a 20L fuel holder, a 9kg gas bottle, and a center section lined with marine-grade carpet for secure storage.
Safety Technology.
The LXV 4.7 is engineered with the latest technology for ultimate safety, featuring a breakaway controller and 12-inch electric brakes as standard. Want even greater stopping power? Ask our sales team about the optional disc brake upgrade at extra cost.
This is only the beginning.
Want to see more features?
.
LXV 4.7 Brochure Request
Enter your details into the form above to receive a link to a brochure in your email.
If you have any questions, please call us on (02)6040 4488
LXV 4.7 Showcase
Want a comprehensive video that walks you through specs, features and construction of our Luxury Offroad LXV 4.7?
Look no further…
